D371X worm gear wafer type soft seal butterfly valve

D371X worm gear wafer type soft seal butterfly valve

Product Details

Product name: D371X worm gear drive wafer type soft seal butterfly valve


The soft seal butterfly valve adopts double eccentric flange butterfly valve with compact structure, easy to switch at 90 °, reliable sealing and long service life. It is widely used in water supply and drainage systems, such as water supply plants and power plants. It is used for adjustment and cut-off of steel mills, paper industry, chemical industry and catering industry.


Features of D371X worm gear wafer type soft seal butterfly valve:

1. The sealing pair is made of stainless steel and nitrile oil resistant rubber, with long service life.

2. The rubber sealing ring can be located on the valve body or on the butterfly plate. It can be suitable for different media for users to choose.

3. The valve has unique structure, flexible operation, labor saving and convenience.

4. The butterfly plate is of frame structure with high strength, large flow area and small flow resistance.

5. The soft seal butterfly valve adopts the double eccentric structure, with the sealing function of closing more tightly, and the sealing performance is reliable.

6. The valve has the function of two-way sealing. It is not controlled by the flow direction of the medium or affected by the space position during installation. It can be installed in any direction.

7. The overall paint baking can effectively prevent corrosion and can be used in different media as long as the sealing material of the sealing valve seat is replaced.
